NP2-BD Series Selector Switch 2-Position / 3-Position Complete with 2NO Contacts

The CHINT NP2-BD Series selector switches are complete operator elements for 22mm panel cut-outs, combining a metal rotary selector head with pre-fitted contact blocks for direct installation into control panels and enclosures. Available in 2-position and 3-position configurations, each fitted with 2NO contacts as standard, they provide reliable and repeatable manual selection for motor direction control, speed selection, mode switching, and similar control circuit applications.

• Rotary selector switch complete with contact blocks — ready to install
• 2-position and 3-position configurations available
• 2NO contacts pre-fitted as standard
• 22mm panel cut-out — fits standard control panel layouts
• Metal actuator for robust industrial performance
• Compatible with NP2 series enclosures and accessories

• Series: NP2-BD
• Positions: 2-position, 3-position
• Contact configuration: 2NO (pre-fitted)
• Panel cut-out: 22mm
• Actuator: Metal rotary
• Brand: CHINT

CHINT NP2-BD selector switches — 2-position and 3-position, 2NO, 22mm, complete and ready to install in control panels. Buy online from Beacon Lighting.
